HP ProLiant DL120 G9 1U Rack Server
Soort optische drive 	DVD-RW
Netvoeding 	550 W
Aantal hoofdvoedingen 	1
Redundante voeding 	Nee
Intern geheugentype 	DDR4-SDRAM
Kloksnelheid geheugen 	2400 MHz
ECC 	Ja
Geheugenslots 	8 DIMM
Maximum intern geheugen 	256 GB
Intern geheugen 	1x 8 GB
Hoogte 	42.9 mm Diepte 	607 mm Breedte 	434.6 mm
Harde schijf-interface 	SATA
Ethernet LAN 	Ja, Gigabit Ethernet
Harde schijf, omvang 	3.5 "
Maximum aantal schijven per behuizing 	4
Maximale opslagcapaciteit 	32 TB
RAID support 	Ja
Grafische adapter 	G200eH2
Grafische adapter-familie 	Matrox
Aantal USB 2.0-poorten 	1
Aantal Ethernet LAN (RJ-45)-poorten 	2
VGA (D-Sub)poort(en) 	1
Aantal poorten USB 3.0 (3.1 Gen 1) Type A 	2
Compatibele besturingssystemen 	Microsoft Windows Server, Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server (SLES), VMware
Inclusief besturingssysteem 	Nee
Ondersteunde instructie sets 	AVX 2.0
Processor lithografie 	14 nm
Chipset moederbord 	Intel C610 LGA 2011-v3
Stepping 	R0
Aantal geïnstalleerde processoren 	1
Processormodel 	E5-2603V4
Aantal processorkernen 	6
Processorcode 	SR2P0
Systeembus 	6.4 GT/s
Processor operating modes 	64-bit
Processor cache 	15 MB
Thermal Monitoring Technologies 	Ja
Idle States 	Ja
Execute Disable Bit 	Ja
Schaalbaarheid 	2s
Physical Address Extension (PAE) 	Ja
aantal QPI links 	2
Tcase 	73 °C
Bus type 	QPI
Thermal Design Power (TDP) 	85 W
Maximaal aantal PCI Express-lijnen 	40
Processorserie 	Intel Xeon E5-2600 v4
Physical Address Extension (PAE) 	46 Bit
Frequentie van processor 	1.7 GHz
Intel® vPro™ Technology 	Ja
Intel® Trusted Execution Technology 	Ja
Intel® AES New Instructions (Intel® AES-NI) 	Ja
Enhanced Intel SpeedStep Technology 	Ja
Intel® Demand Based Switching 	Ja
Intel® VT-x with Extended Page Tables (EPT) 	Ja
Intel® Enhanced Halt State 	Ja
CPU configuratie (max) 	2
Intel® Secure Key 	Ja
Intel® TSX-NI 	Ja
Intel® 64 	Ja
Intel® OS Guard 	Ja
Intel® Virtualization Technology for Directed I/O (VT-d) 	Ja
Intel® Virtualization Technology (VT-x) 	Ja
ARK ID processor 	92993
Soorten RAID 	0, 1, 1+0, 5
Type behuizing 	Rack (1U)
PCI Express slots versie 	3.0
